The compact document scanner takes its place quickly, with high performance and flexibility in the most demanding and fastest operating environments.

Compact, modern design and high-performance, efficiency-oriented functions
Small size, high performance – the imageFORMULA DR-C230 ensures perfect reliability and impressive efficiency at an affordable price. The robust desktop scanner can easily scan multiple document formats and sizes at the same time.

Outstanding performance
Capable of scanning speeds of up to 30 pages per minute and 60 images per minute, the imageFORMULA DR-C230 ensures exceptional efficiency and is available at an extremely affordable price.

The highest level of reliability in its category
The DR-C230 is designed for maximum reliability. Its 60-sheet automatic document feeder is suitable for receiving media of various sizes and can scan up to 3,500 pages per day.

Simple, fast scanning
This convenient desktop model allows users to scan with one button and offers useful features such as automatic page size and text orientation detection.

A wide selection of software
With an impressive range of applications, the DR-C230 has the right tool for every job, including CapturePerfect and CaptureOnTouch V4 Pro software.

Cost-effective operation
Consuming only 19 W during use and 1.4 W when ready, the DR-C230 is not only environmentally and materially efficient, but also provides excellent performance.

Specifications

GENERAL PRODUCT INFORMATION
- Type: Desktop scanner with sheet feeder
- Scanning sensor unit: CMOS CIS 1 line sensor
- Optical resolution: 600 dpi
- Light source: RGB LED
- Scan page: Front/Back/Duplex
- Connector: High-speed USB 2.0
- Size: With trays closed: 291 × 253 × 231 mm, With trays open: 291 × 603 × 363 mm
- Weight: 2.8 kg
- Power requirement: 100~240 V AC (50/60 Hz)
- Power consumption: Scanning: up to 19 W, Standby mode: up to 1.4 W, With power off: up to 0.1 W
- Operating conditions: 10 ~ 32.5°C
- Humidity: 20-80%

SCAN CHARACTERISTICS
- Black and white: 30 pages/minute / 60 images/minute
- Color: 30 pages/minute / 60 images/minute
- Output resolution: 150×150 dpi, 200×200 dpi, 240×240 dpi, 300×300 dpi, 400×400 dpi, 600×600 dpi
- Output Mode: Black & White/Error Distribution/Special Text Correction/Special Text Correction II, 8-bit grayscale (256 levels), 24-bit color depth
- Recommended daily load capacity: 3,500 scanned pages

DOCUMENT CHARACTERISTICS
- Width: 50.8–216 mm
- Length: 54–356 mm
- Thickness: 27-209 g/m² (0.06-0.25 mm)
- Long document mode: max 3000 mm
- Business card scanning: Size: 50.8×85mm or larger, Thickness: less than 0.45mm
- Scanning of plastic cards: Size: 53.9×85.5 mm, Thickness: 0.76 mm (embossed cards are supported up to a thickness of 1.4 mm)
- Passport scanning: Up to a thickness of 4 mm (using a carrier sheet)
- Paper separation: Return roller method
- Feeding capacity: 60 sheets (80 g/m²)

SPECIAL FUNCTIONS
- Automatic page size detection, straightening, three-dimensional color correction, color rendering (RGB), color correction (RGB), automatic color detection, shadow removal, MultiStream, adjustable gamma settings, blank page skip, curved sheet mode, scan area adjustment, document ID, batch separation with white, blank page or with document ID, moiré reduction, reverse visibility elimination/background removal, contrast adjustment, background smoothing, shadow removal, automatic resolution adjustment, double-indent release, double-indent sensor (ultrasonic sensor, based on length)

ACCESSORY SOFTWARE
- Windows: ISIS/TWAIN driver (Windows 7 SP1/8.1/10. Windows Server 2008 R2 SP1/Server 2012 R2/Server 2016), CapturePerfect, CaptureOnTouch V4
- Mac: Support 10.10, 10.11, 10.12
