UBIQUITI USW-PRO-48

Expand and nourish your network at UniFi Switch Pro 48, which is part of Ubiquiti Uni Enterprise System.

Characteristics of layer 3
In addition to the switching protocols and services of layer 2, the Unifi Switch Pro 48 also offers layer 3 capabilities such as VLAN routing, static routing and DHCP server. (Available in a future software release)

Almost quiet cooling
The Unifi Switch Pro 48 is found in any workspace. It has built -in fans with built -in energy management control, ducts and coverings, and temperature sensors for the best user experience.

Fiber
SFP+ ports allow high-capacity up to 10 Gbps Uplinks to connect directly to a high-performance storage server or install remote uplink on another Switch.

Redundant power supply
The Uni Switch Pro 48 supports the external DC input interface, the patented UniFi Switch Pro Redundant Power Supply Interface as a redundant power supply function as a safety reserve when the internal power supply fails.

- 40 pieces of gigabit RJ45 port 802.3AF/AT
- 8 pieces of gigabit RJ45 port with 802.3BT support
- 4 pieces of 10 gigabit SFP+ port
- mounted in 1U rack (console accessory)

Innovative display
The 1.3 -inch touch screen states information for easy observation and quick troubleshooting.

Technical data
- Size: 442.4 mm x 399.6 mm x 43.7 mm
- Weight: 6.25 kg, 6.34 kg (with rack assembly console)
- 48 pieces of 10/100/1000 Mbps RJ-45 port
- 4 pieces of 10 gigabit SFP+ port
- Interface: Ethernet lane
- Power Method: Universal Input: 100 V ~ 240 V AC, 50 Hz ~ 60 Hz
- UNIFI Switch Pro Redundant Power Supply DC Input: 52 V DC, 11.54 A; 11.5 V DC, 5.22 a
- Power supply: AC/DC, internal, 660 W
- Supported Voltage Range: 100 V 240 V AC
- ESD/EMP Protection: Air: ± 16 kv, contact: ± 12 kv
-Flashing and Vibration: ETSI300-019-1.4 standard
- Operating temperature: -5 ° C ~ +40 ° C
- Operating humidity: 10% ~ 90%
- Voltage range: 802.3AF mode: 44 V ~ 57 V, 802.3AT/BT mode: 50 V ~ 57 V
