The world's largest capacity WiFi AP

802.11AC Wave2 Quad-Radio WiFi AP with 10 Gigabit Ethernet and 1500 client capacity support.

Create a future 10 gigabit UniFi network.

The highest performing WiFi AP in the world
High-density tests on Access Points that take place in a high-density environment, with 100 WiFi clients performing the test simultaneously.

Spectral security
The UniFi WiFi AP provides unprecedented wireless awareness and security, including real-time spectrum monitoring tools, RF usage analysis, and intrusion detection/prevention tools. With continuous spectral scanning, the AP constantly monitors the RF environment to check for both potential malicious activity and the best network channel.

Advanced features in the UniFi Controller
With an intuitive user interface, UniFi Controller leads to centralized control of UniFi devices through device discovery, monitoring, supervision and configuration.

Scalable corporate Wi-Fi management
The UniFi ecosystem enables system integrators to efficiently create wireless networks of any size, small-scale, large-scale, with unlimited scalability.

The UniFi XG AP's built-in, dedicated security and monitoring radio provides visibility into site performance, channel design, and local interference, allowing the integrator to properly assess performance and quickly respond to changing interference and security threats.

Easily accessible via any standard web browser and the UniFi app (iOS or Android), the UniFi Controller software is a powerful software engine ideal for deploying low-latency, high-performance, high-density clients.

- Powerful hardware: UniFi XG AP features the latest Wi-Fi 802.11ac Wave 2 MU-MIMO technology combined with dedicated security and Bluetooth radios.
- Intuitive UniFi control software: The system integrator can easily configure and administer the controller for the corporate Wi-Fi network.
- Scalable: A system integrator can start with one (or upgrades to multiple) packages and expand to thousands while maintaining a single unified management system.
- Saves money and time: UniFi comes with a software controller that can be installed on an on-site PC, Mac or Linux machine; in a private cloud; or by using a public cloud service. For more information about UniFi Cloud or UniFi Elite, visit unifi.ubnt.com.

Extends coverage
With NOC or cloud-based UniFi Controller software, system integrators can manage multiple sites: multiple, distributed deployments and additional leases for managed service providers. Below are some installation examples.
With NOC or cloud-based UniFi Controller software, system integrators can manage multiple sites: multiple, distributed deployments and additional leases for managed service providers.

Deploy the UniFi XG AP in very high-density environments that require maximum wireless performance. The UniFi XG AP features simultaneous dual-band 4x4 MU-MIMO technology and convenient 802.3bt PoE compatibility.

- Quad-Radio Capabilities: Three client radios provide unmatched Wi-Fi performance, while a dedicated security radio provides persistent threat management.
- Superior processing performance: The UniFi XG AP is capable of complex operations (guest control, filtering, and other resource-intensive tasks) that can slow down a lesser-equipped AP.
- 10 and 1 Gigabit Ethernet connection: designed for 10 Gigabit Ethernet backhaul, the primary port carries both data and PoE, while the secondary Gigabit Ethernet port is used for bridging and supports PoE input as well.
- Easy to install: The slim design fits perfectly into any environment (all additional accessories) and is compatible with existing UAP-AC-PRO mounts.
- LED: The unique LED service ring provides administrators with location and alerts on all devices.

- Environment: Indoor or outdoor (indoor)
- Simultaneous dual band
- 2.4 GHz: 800 Mbps, MIMO 4x4
- 5 GHz: 2 1733 Mbps, MIMO 4x4
- Dedicated security radio
- Secondary Ethernet port
- PoE mode: 802.3bt PoE
- Can be attached to a ceiling/wall/connection box
- Wireless Uplink
- WIPS

Technical data
- Size: 228 x 228 x 50 mm
- Weight: 1.20 kg
- 1 Gigabit Ethernet port
- 1 10 Gigabit ICM Ethernet port
- Antenna: 6 dBi at 2.4 GHz, 8 dBi at 5 GHz
- 802.11 a/b/g/n/ac/ac-wave2
- Operating temperature: -10°C ~ +60°C
- Operating humidity: 5% ~ 95%
