The UPS1000-i series provides clean and continuous power supply with reliable, real double conversion technology, up to 94%efficiency. Microprocessor control, broad input voltage range (110-300 V) and advanced battery charge system ensure optimum operation even in challenging environments. Compatibility with the generator, ECO mode and various communication options are ideal for protecting sensitive systems, where stability and efficiency are a primary consideration.

Input:
- Nominal voltage: 200/208/220/230/240 VAC
-Input voltage range: 110-300 VAC (at 50% load), 160-300 VAC (100% load)
- Frequency range: 40Hz - 70Hz
- Power factor: ≥ 0.99 at rated voltage with 100%load
- Thdi: ≤ at 5% rated voltage at 100% load

Output:
- Output voltage: 200/208/220/230/240 VAC
- AC voltage control (in battery mode): ± 1% frequency (synchronized range) 47-53 Hz or 57-63 Hz
- Frequency (in battery mode): 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
- Crest factor: 3: 1
- harmonic distortion ≤ 2% thd (at linear load); ≤ 5% thd (for non -linear load)
- Scratch time: AC mode to DC 0, from inverter to bypass 4 ms, from ECO mode battery 8 ms, 10 ms (max)
- waveform (battery mode): pure sinus wave

Efficiency:
- in Eco mode: With full battery recovery 96%
- in AC mode: With full battery recovery 92%
- in battery mode: 86%

Battery:
- Type: 12V/9ah
- Number of pieces: 2
- Refill time: approx. 4 hours to reach 90%of the capacity (for an internal battery)
- Filling current (Default): 1.5a
- Filling voltage: 27.4 VDC ± 1%

Display:
- LCD
- displayed data: load level, battery level, AC mode, battery mode, bypass mode, error message

Communication:
- Smart RS-232 or USB (Windows®, Linux, UNIX, Mac Support)
- Optional Expansion: Network Survey from SNMP Manager and Web browser
