The cento CK 165 F is a two-way sound system is made up of the C 165 F deep speaker and the C 26 high-radiator, to which the CCX 2 cross-gearbox adjusts the appropriate frequency ranges.
The Cento C 165 F is a deep-speaker with a flat profile. Thanks to an extremely flat basket with a reduced installation depth, which facilitates installation in the most complex cases and in new generation cars. The Hertz R&D team was able to achieve great performance with a super flat basket through an extensive design process. This and the new geometric design of the membrane and dust protection allowed it to optimize it. Like the other speakers of the Cento product line, SPP-M (Semi-Paper-Mica) semi-pressed paper star provides a light and rigid membrane for C 165, while guaranteing high efficiency and extended frequency range.
The C 26 high-radiator has a 26 mm soft tetolon dome and 20 mm coil for detailed and natural return of the high sound range. The HERTZ R&D team has worked hard with FEM (Finite Element Analysis) technique for its C 26 radiation properties to maximize performance, combining naturalness. The neodymium magnet optimizes the high-energy dynamic transition in the medium-high frequency range with its strong magnetic field. To facilitate installation in the factory location, the box contains several types of accessories.

Features:

- C 26 high-radiator:

-26 mm Soft Tetolon® Cathedral Dome and 20 mm sound coil provides a natural and detailed reproduction of musical shades.
-High flux-density neodymium magnet controls the medium-high range.
- 3. FEM (Finite Element Modeling) optimized front panel geometry is responsible for even frequency transfer.
- A wide selection of accessories makes installation simple (OEM).

- C 165 F Deep Speaker:

- Flat design for simple replacement of factory (OEM) speakers.
-My semi pressed paper-m (Semi Paper-Mica), reinforced with mica powder, creating a perfect balance between lightness and damping.
- High -density ferritma magnet combined with low carbon sheets for free, high performance levels.
- 25 mm clean copper coil to aluminum cylinder provides very good thermal and mechanical capacity.
- Aesthetic grid with high resistance ABS plastic frame and metal grid provides protection.

- CCX 2 Sound Shift:

- The high-ray color is adjustable between a three-position switch (0, +3 pcs) to achieve optimum balance.
- Capacitors and clean copper coils with a loss of loss factor ensure that even, clean high sounds are transmitted to the high-radiator.
- Small, metal -effect design for easy installation, providing efficient heat folding on the side of the box.

- Specifications:

- Design: 2 passenger speaker sets
- Deep speaker diameter: 165 mm
- High-ray diameter: 26 mm
- Deep speaker coil diameter: 25 mm
- High-ray roll diameter: 20 mm
- Maximum power: 270 W
- Nominal power (RMS): 90 W
- Sensitivity: 93 pcs
- Impedance: 4 ohm
- Frequency transfer: 65 Hz 22.5 khz
- Cross frequency: 2.5 kHz, 12 pcs / oct.
- Deep speaker weight: 0.72 kg
- High-ray weight: 0.03 kg
- Hamg -changer mass: 0.185 kg
