Compact and versatile scanner for the office

The fi-800R can reach a scanning speed of 40 pages/80 images per minute with ADF and 3.5 seconds per page with manual feeding (A4 portrait, color, 200/300 dpi) and can scan 4,500 pages per day.

With its compact design, the scanner is ideal for use in confined spaces, allowing better customer access in areas such as receptions and service desks. Its unique technologies facilitate the scanning of booklets and continuous ADF documents with stable feeding and reduce operator workload, enabling users to provide better customer service.

- Return scan for passports and identity cards
- Rotary scanning with automatic loading technology for convenient continuous scanning
- Automatic skew correction and active separation structure for reliable dosing
- Together with PaperStream IP and PaperStream Capture, it provides advanced image processing functions
- PaperStream Capture Pro is available as an option

Image processing functions
- Multiple image output
- Automatic color detection
- Blank page detection
- Static threshold value
- Dynamic Threshold (iDTC)
- Special error code
- SDTC
- Error propagation
- Trembling
- De-grid
- Emphasis
- Extrusion Color (None/Red/Green/Blue/White/Saturation/Custom)
- SRGB output
- Cutting
- Cutting index tab
- Split image
- Slippage
- Wind correction
- Reduction of vertical stripes
- Character extraction
- Remove background pattern

Specifications
- Type: Automatic sheet feeder/Manual feeding, Double-sided
- Scanning speed (200/300 dpi): Automatic sheet feeder: One-sided: 40 pages per minute, Two-sided: 80 images per minute; Manual dosing: 3.5 seconds
- Image sensor type: 2 CIS, front/rear
- Light source: RGB LED, front/back
- Optical resolution: 600 dpi
- Output resolution: 50 dpi ~ 600 dpi (adjustable in 1 dpi steps), 1200 dpi (driver)
- Output format: Color: 24-bit, Grayscale: 8-bit, Black-and-white: 1-bit
- Background color: White
- Document size: 50.8 mm x 50.8 mm ~ 215.9 mm x 355.6 mm
- Long side scanning: 5588 mm
- Paper weight/thickness: Automatic document feeder: Paper: 40 g/m² ~ 127 g/m², A6 or smaller: 40 g/m² ~ 209 g/m², A8 or smaller: 127 g/m² ~ 209 g/m²; Manual feed: Paper: 20 g/m² ~ 413 g/m², Plastic card: 1.4 mm or less, Booklet: 5 mm or less
- Automatic sheet feeder capacity: 20 sheets (A4 80 g/m² or letter), 30 sheets (A4 52 g/m² or letter)
- Daily load capacity: 4,500 sheets
- Multiple dosing detection: Overlap detection, ultrasonic sensor
- Interface: USB 3.2 Gen 1x1 port
- Power requirement: AC 100 V ~ 240 V ± 10%
- Power consumption: Operating: 19 W or less, Sleep mode: 1.7 W or less, Auto standby/Off mode: 0.15 W or less
- Operating temperature: 5°C ~ 35°C
- Operating humidity: 20% ~ 80%
- Size: 296mm x 105mm x 83mm
- Weight: 2 kg
- Supported OS: Windows 10/8.1/7/Server 2019/2016/2012 R2/2012/2008 R2/2008
- Included software: PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver, PaperStream Capture, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap, Scanner Central Admin

Accessories
- Network Cable
- Network Adapter
- USB cable
- Setup DVD-ROM
