The Creality CR-Scan Otter is a versatile 3D scanner that excels in its ability to accurately scan objects of various sizes, from the smallest objects of 10x10x10 mm to large objects of 2000x2000x2000 mm. Using innovative four stereo lens technology, the scanner handles a wide range of scanning tasks while offering exceptional accuracy and detail. CR-Scan Otter is the ideal tool for both professionals and amateurs who want to create accurate 3D models of a wide range of objects.

The CR-Scan Otter is equipped with two pairs of lenses that allow accurate scanning of small and large objects. Long-focus lenses perfectly capture the details of small objects, while short-focus lenses are ideal for scanning larger objects. This allows users to scan objects of any shape and size with the best quality.

The CR-Scan Otter 3D scanner offers remarkable accuracy: it reaches 0.02 mm at a distance of 60 mm from the object. Thanks to its advanced stereo algorithm and structured infrared light technology, the device reproduces the authentic structure and contours of objects, so that every detail becomes clear and precise. A scanning speed of up to 20 frames per second and anti-shake technology ensure smooth and efficient scanning, even while moving.

CR-Scan Otter can handle difficult-to-scan surfaces, such as black and metallic objects, without special spraying. The device is equipped with a 24-bit RGB camera and two additional LEDs that provide strong illumination and accurate color reproduction. This ensures that scanned objects retain their natural colors and textures, which is especially important for applications that require colorful 3D models.

CR-Scan Otter supports Windows and macOS, and will be compatible with Android and iOS devices in the future with additional wireless scanning accessories. The tool supports different alignment modes, including geometry, marker and texture adjustment modes, making it more versatile for different projects. Output can be exported to popular formats such as OBJ, STL and PLY for easy integration into 3D modeling software.

With a built-in LED ring for monitoring operational status and an intuitive user interface, the Creality CR-Scan Otter provides convenient and efficient scanning. The ability to adjust exposure and other parameters in real-time allows you to fine-tune the settings according to the current conditions, resulting in a better final result. Whether scanning small, complex or large objects, the CR-Scan Otter delivers exceptional quality and detail to satisfy even the most demanding users.

Technical data
- Accuracy: up to 0.02 mm at 60 mm
- 3D resolution: 0.05-2 mm
- Scan speed: Up to 20 frames per second (fps)
- Minimum scanning volume: 10 mm × 10 mm × 10 mm
- Single recording range: max. 1350 × 840 mm by 1000 mm
- Technology: Structured infrared light
- Working distance: 110 mm 1000 mm
- Color mapping: Yes
- Alignment modes: Geometric/Marker/Texture
- Output format: OBJ/STL/PLY
- IMU (Inertia Measurement Unit): Yes
- Additional lighting: 2 white LEDs
- Marker recognition amplification: 8 infrared LEDs
- Laser safety: Class I (eye safe)
- Supported systems: Windows/macOS (Additional wireless scanning accessories are required for iPhone iOS/Android system)
- Wireless Scanning: Supported with future wireless scanning accessories
- Buttons: Touch
- Sound signals: Yes
- Calibration table: Yes
- Operating temperature range: between -10°C and 40°C
- Operating humidity: 0-90% relative humidity
- Power supply: 5V 3A
- Data interface: Type C/USB3.0/USB2.0
- Dimensions of the device: 165 mm x 37 mm x 59 mm
- Weight of the device: 390 g
