5200 lumen brightness

Crystal clear and vivid images even from afar in auditoriums or any large venue with a brightness of up to 5200 lumens.

FHD resolution

The stunningly beautiful 1080p Full HD 100” image looks as real as if you were looking out the window.

1.3x magnification ratio

Make the most of your space with a zoom ratio that's ideal for medium-sized meeting rooms.

Acer ColorSafe II

Enjoy consistent and natural colors with ColorSafe II technology, which prevents color loss by controlling dynamic RGB levels.

Vertical and horizontal keystone correction

Fix distortion in the corners quickly and easily with vertical and horizontal keystone correction.

With automatic keystone correction against distortion

Say goodbye to distorted images - this projector automatically corrects horizontal and vertical image distortions, ensuring a perfect projection from every angle.

It can be used all day, every day of the week

This projector also allows continuous use, making it an ideal choice for public presentations and exhibitions.

Environmentally friendly Acer EcoProjection

You can reduce energy consumption by up to 70% and extend lamp life up to 15,000 hours with Acer EcoProjection technology.

Description:

Display/Image

- Projection system: DLP™
- Light source: Philips 240 W E20.7i
- Basic resolution: 1920 x 1080
- Maximum resolution: 1920 x 1200
- Brightness: 5200 lm (Standard), 4160 lm (ECO), (Meets the requirements of the ISO 21118 standard)
- Aspect ratio: 16:9 (Native), 4:3 (Supported)
- Contrast ratio: 18,000:1
- Image diameter size: 31" (78.7cm) ~ 7.62m (300")
- Projection ratio: 1.13 to 1.47 (1524 mm@1500 mm)
- Zoom ratio: 1.3x
- Lens: F = f/2.43~f/2.78, f = 16.90mm~21.61mm, Manual zoom, Manual focus
- Projection offset (Half height): 116%
- Projection mode: Front, Back, Front ceiling, Rear ceiling
- Display color: 1.07 billion
- Vertical sync frequency: 24 ~ 120 Hz
- Horizontal synchronization frequency: 15 to 100 kHz

Connectors/connectors

- HDMI: HDMI1.4b (HDCP 1.4) x 2
- HDBaseT: x1, RJ45
- Audio input: x1, 3.5mm mini jack
- Audio output: x1, 3.5mm mini jack
- USB Type-A output: x1, DC Out (5V/1.5A)
- Speaker: x1, 10 W Speaker

Control and Network

- RS232: x1, D-sub
- Lan Ctrl: x1, RJ45
- Network control protocols: Crestron

General

- 3D support: DLP™ 3D
- Security: Kensington lock, Security lock

Current

- Power consumption: 290 W (Standard), 210 W (ECO), 0.5 W (Standby)

Physical properties

- Installation: Can be installed on the ceiling
- Dimensions (W x D x H): 313 mm x 236 mm x 113.70 mm
- Weight (approximate): 2.8 kg
