- Optical system: 2500 Pixel sensor
- MCU CPU: 32-bit CPU processor
- Scanning speed: 200 Scan/sec
- Light source: RED LED (660nm)
- Resolution: 0.1mm (4 mil)
- Scanning angle: 45°
- Scanning width: Up to 180mm or more (PCS90%)
- Scanning distance: (PCS 90% code 39): 0mm-10mm (4mil), 0mm-30mm (5mil), 10mm-100mm (10.5mil), 30mm-1400mm (13mil)
- Host system interface: USB (HID) interface
- Scan Distance (PCS 90% code 39): Code 39, Full ASCII Code 39, Code 32, Code 128, Code 93, Code 11, Codabar/NW7, All UPC/EAN/JAN Codes (EAN-13, EAN-8 , UPC-A, UPC-E, EAN-128), Interleave 2 - 5, STD 2 - 5, Industrial 2 - 5, matrix 2 - 5, China Postage Code, IATA, MSI/PLESSY, Italian Pharmacy Code.
- Decoding option: RRS-14, RRS limited, RRS Extended
- Operating temperature: 0? - 50?
- Material: ABS plastic + rubber
- Size (LxWxH): 160 x 80 x 20mm
