Shelly Wave H&T is an element-based Z-Wave Long Range protocol communicating temperature and humidity measurement that will help you maintain a hydrated and healthy indoor environment. The device has an elegant, compact design, placed anywhere and has a long battery life (~ 1-2 years in Type CR123A). Easy to integrate with Z-Wave Hub, automatic communication, firmware update and SmartStart support.
This product belongs to the Shelly Wave (Z-WAVE) series and is different from the traditional Wi-Fi H&T family: it uses not Wi-Fi but Z-Wave Long Range, so it can be fitted into another network ecosystem.

Z-Wave® Protocol-Overview

The Z-Wave® protocol is an interoperable, wireless radio-based communication technology designed specifically for control, observation and recording in residential and light industrial environment. As a proven and widespread solution, Z-Wave® is far from the world market leader in control systems, offering affordable, reliable and easy to use "smart" products in all areas of our daily lives. Interoperability has always been a central element of the Z-Wave® protocol, with features such as backward compatibility, security and reliability. Each Z-Wave® device can operate in any Z-WAVE® network with other devices with Z-Wave® certification, regardless of manufacturer or brand. In the network, all network nodes that operate with a network current also function as a transmission, regardless of manufacturer, thus increasing the reliability of the network. There are more than 4,000 Z-Wave® certified products that are backward and forward compatible in the Z-Wave® ecosystem and currently has more than 100 million devices on the market. Z-Wave® technology has a market presence over 20 years and offers outstanding security measures to make your home network smarter and safer.

Main product features

- Humidity Sensor: Precise humidity measurement, helps prevent too dry air or mold
- Temperature Sensor: Exact temperature measurement to maintain a comfortable environment
-Z-Wave Long Range Technology:> 400m range (line) and Z-Wave 800 chip, Security S2 support
- Battery Powered: 1 × CR123A item up to 2 years of operation
- SmartStart, OTA Firmware: Easy Network Connect and Automatic Update
- LED and button: Built -in status LED, S Button for reset and network connection

Smart home protocols and platform compatibility

- Protocol: Z -Wave Long Range and Classic Z -Wave Support (868 MHz EU)
- Local control: via Z -Wave Hub, Hub is required
- Factory compatibility: all certified Z -Wave gateway signs (Homey, Fibaro, Aeotec, etc.)
- Security: Z -Wave S0/S2 (Authenticated) Security Protocols
- Integration: MQTT is not through Z -Wave protocol
- Voice Control: Not directly via Hub is available remote control (eg Alexa, Google Assistant through Hub)

Smart features

- Remote Reading: Requestable heat through Z -Wave Hub./Humidity
- Notifications: Possible with Hub Automation (eg Signal If Humidity> 70%)
- can be attached to other devices: can be used as a basis for sensory data for scenes
- OTA Update: Using Automatic Firmware Update Hub
- SmartStart: Simple Connection Battery Insert + button Activate

Electricity functions

- Power voltage: 3V CR123A item
- Battery life: up to 2 years (depending on hub interactions)
- Outputs / Inputs: There is no only measuring module
- Consumption: ultra -lowony (<70µa sleeping)
- Power supply is independent: it works exclusively from battery;

Other features

- Compact, modern design
- Z-Wave 800 chip low consumption, high range
- Smart Stock Security Support: Simple and Safe Network Connect
- Wireless packaged, hub required for configuration
- Ideal for indoor use Mold, to prevent drought

Description:

- Manufacturer: Shelly
- Factory article number: FG3800238071196
- Plug & Play Installation: Yes

Operation / Operation

- Operational power supply: CR123A element (3V)
- Operating ambient temperature: 20 ° C-40 ° C
- Operating Environmental Humidity: 30% -70% RH
- IP protection: IP20

Supported protocols

- Wi-Fi: No
- Zigbee: No
- Thread: No
- Z-Wave: Yes
- RF / Radio Control: No
- Bluetooth: No

Smart features

- Notification Functions: Yes
- History / Event Log: Yes

Other

-Article number: All-Kie-Wave-HTW
- Communication protocols: Z-Wave
- Main category: Temperature and humidity sensor
- Barcode: 3800238071196
- Dimensions: 4.5 × 4.5 × 3.5 cm
