- Optimizer: Coming soon to the M1 series (M0 series is not supported by software, but the optimization is performed by the system)
- Weight (with support structure): 17 kg
- Size (including support structure): 525 x 470 x 166 mm
- Warranty: 10-year replacement warranty can be extended to 20 years
- Communication: Built-in Wifi module
- Max. efficiency: 98.4 %
- Recommended max. PV power: 10,000 Wp
- Max. input voltage: 1.100 V
- Starting voltage: 200 V
- MPPT operating voltage range: 140V ~ 980V
- Nominal input voltage: 600 V
- Max. input current / MPPT: 11 A
- Max. short-circuit current: 18 A
- Number of MPP followers: 2
- Battery compatibility: Yes
- Battery support: HUAWEI PowerMate ESS Battery 5kWh 30kWh
- Max charge/discharge power: 6,000 W
- Mains connection: Single-phase
- Rated output power: 5,000 W
- Nominal AC mains frequency: 50 Hz / 60 Hz
- Max. output current: 10.1 A
- DC voltage protection: Yes, compatible with protection class II according to the EN/IEC 61643-11 standard
- AC voltage protection: Yes, compatible with protection class II according to the EN/IEC 61643-11 standard
- AC overcurrent protection: Yes
- Operating temperature range: -25 ~ +60 °C (noticeable drop above 45 °C @ rated output power)
