- 1.5–6 mm², Cu 3~
- With terminals, 2 connections per pole
- 5-pole, per pole 6 x 1.5 mm² r / f, 4 x 2.5 mm² r / f, 4 x 4 mm² r / f, 4 x 6 mm² r / f, 2 x 10 mm² r / f
- Flexible sealing membranes that can be removed when using cable entry glands, sealing range O 9.0–21.0 mm
- 1 cable entry option at the bottom of the box, sealing range O 9.0–20.0 mm
- The lid seal can be sealed without an auxiliary device
- Cover wire and external reinforcing tabs for wall mounting included
- Color shade: gray, RAL 7035
- Use an EDK type cable entry to seal the open diaphragms. Protection = IP 66.

Technical data:

- Nominal insulation voltage: Ui = 690 V a.c./d.c.
- Rated current: 40 A
- Base material PP (polypropylene)
- Protection IP 66
- Width: 130 mm
- Height: 130 mm
- Depth: 77 mm
- Weight: 0.245 kg
- Clamp tightening torque: 1.5 Nm
- According to standard IEC 60670-22
