The PS400 is excellent for testing electrical systems, in the petrochemical industry, in building engineering tests and in various industrial plants. The PS400 is one of the best thermal cameras in this resolution category. The 384x288 sensor resolution enables immediate detection, accurate measurement and selection of overheating of electrical and mechanical surfaces on the 5-inch, 1280*720 pixel resolution touch screen, which has excellent brightness even in daylight conditions. Thanks to the ergonomic design of the device, the display can be rotated, so any surface can be conveniently examined with it. Its own viewfinder also has an excellent image, as the manufacturer has installed an LCOS monitor with a resolution of 1280x960 pixels. The Android system running on the camera makes it possible not only to use it simply as a thermal camera, but also to function as a mobile terminal on which many applications can be run.

The device works with an accuracy of +/-2°C or +/-2% in the following temperature intervals:

-40 - +150°C / +100 - 800°C / 700 - 2000°C (in the temperature range of 0 and +100°C up to +/- 0.5°C)

As a professional device, it can provide measurement data for up to 12 different points, along 12 lines, or in 12 different areas at the same time, while the damage can also continuously follow 2 points - all this by compensating for the current atmospheric data. Its emissivity can be adjusted from 0.01 to 1.1.

- High-resolution thermal image and real video image recording even at the same time, along with which notes can be saved
- Continuous digital zoom up to 1 x 10x
- Rotatable lens
- 384x288 IR FPA sensor
- 1280×960 pixel LCOS viewfinder, for fast use and energy saving
- 5-inch 720P (HD) LCD touch screen, brightness sensor
- 8 MP real camera image
- Microphone, voice note, playback with speaker
- Built-in lamp, which can be used to illuminate the examined object while using the real video image, if the lighting conditions are bad
- Laser rangefinder, Bluetooth, digital compass
- GPS, Glonass, 4G, WiFi
- SD card expansion up to 64 GB, mini HDMI output
- Up to 4 hours of operating time, 2.5 hours of charging time up to 90%
- IP54

Rotatable display
The display can be unfolded and tilted 270° along its axis. The excellent ergonomics of the device make long examinations comfortable.

Simple Wi-Fi data transfer
Images and videos can be transferred to mobile devices using Wi-Fi. The thermal camera can be controlled remotely with a smartphone. The result of the test performed on the device can be printed immediately on a Wi-Fi printer.

Android operating system for easy expandability
The Android operating system runs on the device, so the software can be easily updated at any time in the future, and new applications can be installed on it. The sophisticated on-board software enables tests and reports to be prepared directly on the device.

Multiple types of image display: thermal image and real video
The PS400 is suitable for displaying the thermal image and the real video image separately. In addition, it can be used in PIP (picture in picture) and MIF modes. In PIP mode, the real image is also displayed on the thermal image in a smaller window, so you can compare the examination points of the visible and the thermal image. In MIF mode, the thermal image and the real image are combined by software, so that, for example, different inscriptions or details that give a homogeneous thermal image, but in reality separate details on the image, remain visible. Both the heat and the real image can be saved to the memory card in parallel.

Interchangeable lenses
The camera has a 15 mm germanium lens, to which an optional wide-angle and telephoto lens can be attached. It has both automatic and electronic focus. The lens of the device can also be rotated.

Basic accessories of the product
- Thermal camera with 15 mm lens
- Li-Ion battery (2 pcs)
- AC adapter
- Adapter connector (5 pcs)
- USB cable
- HDMI cable
- Network cable
- Brief instructions for use
- Instructions for use
- Product CD (test software)
- List of accessories publication
- Shoulder strap
- 64 GB of internal storage
- Camera carrying case
- Charging dock
- Reinforced tool case
