Gledopto's wireless RF remote control is capable of local remote control of LED controls and LED lighting belonging to the Zigbee Pro product line, using 2.4GHz RF wireless RF technology.

This type can remotely control a maximum of 8 zones / devices / device groups.

The members of the Gledepto Zigbee Pro product family can all be controlled with local RF remote control: with 2.4 GHz RF remote controls and wall-mounted RF panels. And this wireless RF remote control can control up to 8 different smart Gledopto Zigbee Pro LED products.

This is the portable RF remote control type, but Gledopto also offers a wall mounted RF remote control wall panel if that is what is needed.

Compatible with all LED controllers of the Gledopto Pro range (5-in-1, 5-in-1 Mini, CCT (WW/CW), RGBW, RGB CCT, Dimmer), Gledopto Pro LED spotlights, and Gledopto With Pro LED bulbs.

Pairing is a very simple process: after turning on the Zigbee Pro lighting, you only need to press the button ("I") of the selected (1-8) zone on the remote control, and successful pairing is already indicated by the lighting turning on. More than eight devices can be paired with it, if several devices are added to a zone (and controlled together), for example by creating one zone for each room.

Product features:

- This RF remote control is only compatible with Gledopto Pro and Plus products, not with plain Zigbee products, as only these have a 2.4GHz RF receiver in addition to the Zigbee chip.
- Compatible with Gledopto Pro LED controls, LED bulbs, LED spot lights, LED reflectors, LED garden lights
- Milight compatible
- It can also control a group even without a hub, max. It can remotely control devices organized into 8 zones or groups
- Capable of controlling brightness, color temperature and RGB colors:
- to set RGB color (for RGB, RGBW, RGB CCT devices and controllers)
- To adjust brightness: it can also function as a dimmer/brightness control
- It can also set color temperature, i.e. on a cold / warm white light scale for white light (in the case of RGBW, RGB CCT, CCT LEDs)
- It supports 9 modes, so you can create different mood lights
- Uses 2.4GHz RF remote control technology for local remote control, does not require Zigbee or other hubs for operation.
- Range: up to 30 meters
- Transmission power: 6 dBm
- 60-second switch-off, for this you just need to press the "hold" button on the remote control and the device will switch off after 1 minute
- Works with AAA battery
- Material: polycarbonate

Description:

- Manufacturer: Gledopto
- Factory article number: GL-RC-009
- Product type: 2.4 GHz remote control for Gledopto Zigbee Pro products (for remote control of 8 devices/device groups/zones)
- Color: White

Installation / operation

- Operating power supply: 2 AAA batteries
- Connection: Wireless device, does not require connection
- Operating ambient temperature: 20°C-60°C

Controlled (/measured) circuit

- Dimming / Brightness control: Yes, brightness can be controlled from it

Supported protocols

- Wi-Fi: No
- Zigbee: No
- Z-Wave: No
- RF / radio control: Yes, 2.4GHz RF transmitter
- Bluetooth: No

Remote control, smart control

- Direct (local) remote control: This device can remotely control Gledopto Zigbee Pro devices

Other

- Dimensions: 13.0 × 5.5 × 1.8 cm
