2-button IP video door phone outdoor unit

- 2 megapixel HD CMOS camera
- Aluminum panel, IP65, IK08
- ICR Night vision and sound signal
- Video and voice messages
- Remote intercom with mobile app
- Surface mounted

Specifications
- Video compression: H.264
- Image sensor: 1/2.8" 2MP CMOS
- Ignition distance: 1.9 mm
- Viewing angle: 140°
- Day/night: ICR
- Sound compression: G.711
- Sound input: Omnidirectional microphone
- Sound output: Built-in speaker
- Supports two-way conversation
- Keyboard: 2 mechanical keys
- Reader: Mifare card
- Door control connector: 1 piece
- Alarm connector: 2 pieces (1-channel release button, 1-channel feedback)
- RS485: 1 piece
- Ethernet: 10/100 Mbps
- Network protocol: TCP/IP
- Ingress protection: IP65, IK08
- Tamper switch: 1 piece
- Cover: Aluminium
- Power supply: DC 12 V, PoE (802.3af)
- Energy consumption: Standby ≤1 W, Operation ≤7 W
- Operating temperature: -40°C ~ +60°C
- Humidity: 10% ~ 90%
- Size: 182.0 mm × 30.0 mm × 101.0 mm
- Weight: 0.8 kg
