Physical design
- Dimensions: 167 x 53 x 79 mm
- Weight: 1000K model: 250 g; 1000U model: 260 g; 1000R model: 265 g
- Housing: gray, ABS plastic, rubberized, non-mechanical switch
- Impact position: Withstands a drop onto concrete from a height of one meter

Electrical characteristics
- Supply voltage: +5V10%, average 75-110 mA

User environment
- Temperature: 0C°50 C° (Storage: -20C°60 C°)
- Humidity: 20-90% non-condensing (storage: 10-95% non-condensing)
-

Reading parameters
- Head width: 67mm
- Light source: 660 nm red light
- Scanning: 2048 point CCD
- Reading speed: 100 reads/sec
- Resolution: 0.125mm
- Reading distance: 0-29 mm
- Reading width: 67 mm
- Tilt: forward 40°, backward 70°, sideways 30°
- External light sensitivity: Normal office and industrial lighting does not interfere (1200lux direct sunlight, 2500lux fluorescent light)

- Standard barcodes
- Code39/Full ASCII; Plessey; ON THE CITY; codabar; Industrial 2 of 5; RSS14; Matrix 2 of 5; Code93, Code128; EAN128; EAN8&13; MSI; UPCA&E

Programming
- Code identifier, prefix, postfix, code length, volume, tone, barcode types, barcode conversions, character delay, reading mode, terminal type, language, timing, RS232 speed, data bits, half duplex/full duplex, ISBN/ISSN/UK Plessey conversion ; Programmable sound signal

Data editing
- Three editing formats can be handled, conditions for code type, length, matching character sequences can be specified. The data can be divided into six fields, 5 additional fields can be programmed for each format, and the transmission sequence of fields can be programmed.

- USB interface
- Keyboard
- IBM PC/AT, PS2-30
- PC AT languages
- American, English, French, Italian, Belgian, Hungarian, Norwegian, Swedish, Spanish, Portuguese, German
- Appropriateness
- FCC Class-A, CE, C-tick
