CHIEFTEC Vega 850W 80 Plus Gold PSU
not available
Product description
The Chieftec VEGA PPG-850-S PC power supply is an ideal choice for all gamers and demanding users. The power supply is made according to the Intel ATX 12V 3.1 standard and supports PCIe GEN5 technology, thus ensuring future-proof solutions and maximum performance. The 80PLUS Gold certification guarantees high energy efficiency, thereby reducing power consumption and heat production.
- Power: 850 W
- +12V power: 850 W
- +3.3V/+5V power: 100 W
- Input voltage range: 100-240 Volts
- Input current: 6 A at 230 Volts / 50 Hz, 12 A at 110 Volts / 60 Hz
- Standard: ATX12V 3.1
- Size: ATX
- Rating: 80 PLUS Gold
- Currents: +3.3 V: 20 A, +5 V: 20 A, +5 Vsb: 3 A, -12 V: 0.3 A, +12 V: 70.8 A, +12 V1: 70.8 A
- Power factor correction: Active PFC
- Switches: 1x mains switch
- Connectors: 1x 24-Pin-ATX12V-2.x, 1x 4+4-Pin-12V, 3x 4-Pin-5.25", 4x 6+2-Pin-Grafik, 1x 8-Pin-12V, 1x 12VHPWR, 6x 15-Pin-SATA
- Cooling: 1x 135 mm fan, temperature controlled
- Protection functions: OCP (overcurrent protection), OVP (overvoltage protection), UVP (undervoltage protection), OLP/OPP (overload protection), SCP (short circuit protection), OTP (overheating protection), SIP (overvoltage protection)
Innovative Technology and Protection Functions
The excellent quality of the Chieftec VEGA PPG-850-S is ensured by the LLC-Half-Bridge voltage converter and DC-to-DC technology, which increases energy efficiency and stability. The extra long black cables are ideal for building systems in larger houses, and the 135 mm FDB (Fluid Dynamic Bearing) fan optimizes the balance of cooling and noise levels, ensuring quiet and efficient operation.
About the Chieftec Brand
Chieftec has been in the computer hardware market for over 25 years and has built a reputation for reliable, innovative products. The VEGA series also reflects the company's commitment to quality and performance.
