Why choose this tool?
- EC engine without a coal brush: dust protected, compact, light and absolutely maintenance -free
- VIBRATION CONTROL: Independent Handle for Fatty Working
- Long operating time: Drilling up to 216 hole into concrete with a battery charge (6 x 40 mm)
- LED work lamp: workspace for optimum illumination
- Ergonomic Design: The best horizontal power transfer to the hole
- Electronic Cell Protection (ECP): Protects the battery overload, overheating and deep discharge
-Innovative CoolPack Batches: Provide optimum heat exception, so life span is up to 100%(compared
- No memory effect: The battery can be charged independently of the charging state at all times without damaging cells
- The shortest charge time: After 35 minutes, the battery is up to 80%
- a replacement dedication to switch between punch drilling into the concrete and drilling in the tree and metal
-50%more energy with a wired tool's stroke power for fast and flexible work (compared to previous GBH 18 V-EC)
- Increased protection of the operator with Kickback Control (KBC) and increased control of Electronic Precision Control (EPC) technology
- Dust-free drilling with the new integrated and optional GDE 18V-16 dust hood

Technical data
- Punch energy max: 2.6 J
- Bump number on nominal speed (punch/min): 0 - 4350 beats/min
- Nominal speed: 0 - 890 1/min
- battery voltage: 18 V
- Tool holder: SDS-Plus

Drilling range
- Bore diameter in concrete with hammer drill: 4 - 26 mm
- Concrete, hammer drill - optimal occasion. Range: 8 - 16 mm
- Max. Bore diameter in metal: 13 mm
- Max. Wood diameter, wood: 30 mm

Punching in concrete
- Vibration release value AH: 13 m/s²
- Uncertainty K: 1.5 m/s²

Drilling in metal
- Vibration release value AH: 2.5 m/s²
- Uncertainty K: 1.5 m/s²

Screwing
- Vibration release value AH: 2.5 m/s²
- Uncertainty K: 1.5 m/s²
